SILVENT 9002W-Z
The SILVENT 9002W-Z is an energy-efficient flat air nozzle made of zinc, designed to deliver a strong, efficient blowing force while maintaining exceptionally low noise levels. Its aerodynamic design maximizes air entrainment, making it suitable for industrial applications such as drying, cooling, and cleaning.Silvent+5Silvent+5Silvent+5Silvent+5impactrm.com+5Silvent+5
🔧 Key Specifications
Material: Zinc (Zn ZP0410 EN 12844)
Blowing Force: 5.5 N
Air Consumption: 28 Nm³/h
Sound Level: 78 dB(A)
Connection: G 1/4″ male
Weight: 116 g
Maximum Temperature: 70°C
Maximum Operating Pressure: 1.0 MPa
Noise Reduction: 24 dB(A) compared to open pipe
Energy Savings: 39 Nm³/h compared to open pipe
📊 Performance at Various Pressures
| Pressure (kPa) | Blowing Force (N) | Air Consumption (Nm³/h) | Sound Level (dB(A)) |
|---|---|---|---|
| 200 | 2.4 | 13.3 | 69.9 |
| 400 | 4.6 | 23.2 | 76.0 |
| 600 | 6.8 | 33.2 | 79.0 |
| 800 | 8.9 | 43.2 | 84.1 |
| 1000 | 11.1 | 53.1 | 86.4 |
Source: Silvent 9002W-Z Product PageSilvent+2Silvent+2Silvent+2
📐 Blowing Coverage
| Distance (mm) | Blowing Width (mm) |
|---|---|
| 50 | 80 |
| 100 | 110 |
| 200 | 150 |
| 300 | 190 |
Source: Silvent 9002W-Z Product Page
🔩 Installation Features
Equipped with two fastening holes for easy installation.
Designed for use in environments up to 70°C.Silvent
